US scientists claim clear-sky irradiance model provides better results for module testing

Researchers at the American Institute of Physics have used the clear-sky irradiance model developed by the National Renewable Energy Laboratory to measure the degradation rates of solar panels at a testing field in Germany over five years. The scientists say the model, when combined with real-world data, offers an efficient tool to evaluate the aging of PV technology.

Source:pv magazine

An international research team coordinated by the American Institute of Physics claims to have successfully applied the clear-sky methodology developed by the U.S. Department of Energy’s National Renewable Energy Laboratory (NREL), to obtain a more accurate assessment of solar module performance.

According to findings presented in the paper Reliable long-term performance assessment of commercial photovoltaic modules tested under field conditions over 5 years, published in the Journal of Renewable and Sustainable Energy, the open-source, clear-sky methodology – which helps determine solar irradiance at a location in ideal, clear-sky conditions – is a very efficient tool to evaluate the aging of PV technology under field conditions when combined with real-world data. Such extra information is commonly provided by pyranometers, a type of actinometer used for measuring solar irradiance on a planar surface. Pyranometers, said the Institute of Physics team, are often a source of errors and malfunctions but integration with the clear-sky methodology could help reduce inaccuracy.

Five-year test

The clear-sky model was applied for five years to five PV module technologies: micromorph thin film silicon; cadmium telluride (CdTe); copper indium gallium selenium (CIGS); polycrystalline silicon; and amorphous silicon (a-Si), at a 10 kW test field at the Max Planck Institute of Chemical Energy Conversion in Mülheim an der Ruhr, Germany.

Data were recorded once per second by a LogMessage data logger from Delphin and by a pyranometer from Kipp&Zonen. Meteorological data were measured by a Vaisala Weather Transmitter WXT520.

The combination of data from the pyranometers plus that modeled with clear-sky methodology, according to the paper, enabled the researchers to see the difference between the two datasets, highlighting inconsistencies and ensuring accurate performance over time. “The current work also shows that even in cases of serious sensor malfunction, reliable long-term performance assessment can be performed by applying robust aggregation and regression methods, as well as the clear-sky methodology developed at the NREL,” the scientists wrote.

More research needed

The researchers added, although the panel degradation rates measured in the study should not be taken as an indicator of global performance of their respective technologies, the degradation of polycrystalline, a-Si and CdTe panels was stable over the first five years. For modules installed after 2000, the degradation rate was –0.4%, –0.96%, –0.87%, and –0.64% for CdTe, CIGS, poly-Si, and a-Si modules, respectively.

“Our results for poly-Si and a-Si panels are consistent with the previously published data, while the CdTe panels seem to perform worse than expected,” stated the paper. “The wide use of such standardized tools should be strongly advocated as the resulting performance datasets collected from research facilities from all over the world will be more reliable and can contribute to predictive models.”
